Resp Dialog Respiration (Resp)
10 - 6 V Series Operating Instructions
FIGURE 10-4 Example Resp Dialog (Apnea Tab)
3. Select the buttons described in TABLE 10-3 to configure the tab.
4. Select the Cancel or Accept button.
•The Cancel button closes the dialog without saving the settings.
•The Accept button saves the settings and closes the dialog.
TABLE 10-3
FUNCTION DESCRIPTION SETTINGS*
Apnea Alarm Configures whether the apnea alarm is
on or off.
On, Off
Apnea Delay Configures the number of seconds
before the apnea alarm is called.
Adult: 10-60 seconds, 30
Pediatric: 10-20 seconds, 15
Neonate: 10-20 seconds, 15
Apnea Latch Configures whether the apnea alarm is
latched or unlatched. Refer to"Apnea
Latching" on page 7-3
for additional
information.
On, Off
NOTE: When the patient size is Neonate, the
Apnea Latch default setting is On.
* The factory default configuration settings are in bold.
