IBP Dialog Invasive Blood Pressure (IBP)
11 - 6 V Series Operating Instructions
3. Select the buttons described in TABLE 11-2 to configure the tab.
4. Select the Cancel or Accept button.
•The Cancel button closes the dialog without saving the settings.
•The Accept button saves the settings and closes the dialog.
11.2.4.1 Default IBP Waveform Sizes
The default IBP waveform size is 0 to 160 mmHg for all of the generic IBP<channel> labels. The other
IBP labels also have default waveform sizes. TABLE 11-3 outlines these defaults.
TABLE 11-2
BUTTON DESCRIPTION / COMMENTS CHOICES*
Scale Configures the waveform height and width. -10 to 10 mmHg
0 to 20 mmHg
0 to 40 mmHg
0 to 60 mmHg
0 to 80 mmHg
60 to 140 mmHg
0 to 160 mmHg (when labeled an
IBP <channel> number)
0 to 225 mmHg
0 to 320 mmHg
Speed Configures the waveform sweep speed. 6.25 mm/sec.
12.5 mm/sec.
25 mm/sec
50 mm/sec
* The factory default configuration settings are in bold.
TABLE 11-3
LABEL DEFAULT WAVEFORM SIZE
ART and ART2 0 to 160 mmHg
UA 0 to 80 mmHg
LV 0 to 160 mmHg
PA 0 to 40 mmHg
CVP 0 to 20 mmHg
ICP 0 to 20 mmHg
LA 0 to 20 mmHg
RA 0 to 20 mmHg
IAP 0 to 20 mmHg
