Introduction System Setup
26 - 2 V Series Operating Instructions
26.1 Introduction
The V 12/V 21 System Setup dialog provides access to the system default settings such as date and
time format, parameter timeouts, enabling/disabling lethal alarms, Quick Functions buttons, default
printers, service mode, and password updates. Access to this dialog requires a password.
26.2 System Dialog
The System dialog, located in the Setup tab, (as shown in FIGURE 26-1) contains the following tabs:
• General
•Alarms
•Printer
•Network
•Alarm Watch
• System
A description of each tab follows.
26.2.1 Navigating to the System Dialog
1. Select the Setup tab from the Navigation Area.
2. Select the System button.
NOTE: The locked icon in the System button indicates that a
password is required to access the System dialog.
3. Enter the password.
4. Select the Accept button.
The System dialog displays (as shown in FIGURE 26-1).
