V Series Operating Instructions 26 - 3
System Setup System Dialog
FIGURE 26-1 Example System Dialog (General Tab)
26.2.2 Configuring the General Tab
Select the General tab to configure the screen formats, timeouts, display setup, and Quick Functions
buttons. These functions apply to all patient sizes.
1. Select the Setup tab from the Navigation Area.
2. Select the System button, enter the password, then select the Accept button.
3. Select the General tab (as shown in FIGURE 26-1).
NOTE: The current setting displays beside the tab button.
4. Select the buttons described in TABLE 26-1 to configure the tab.
TABLE 26-1
BUTTON DESCRIPTION / COMMENTS CHOICES*
Date Format Changes the format in which dates are
displayed in the system.
D/M/Y, Y/M/D, M/D/Y
Time Format Changes the format in which time is
displayed in the system.
12 Hour, 24 Hour
NIBP Timeout Determines the time interval at which the
NIBP measurement is automatically removed
from the Main Display.
15 min, 30 min, 45 min, 1 hr
CO\PAWP Timeout Determines the time interval at which the
CO/PAWP measurement is automatically
removed from the Main Display.
15 min, 30 min, 45 min, 1 hr
Nurse Call Sends an electronic signal to the Nurse Call
system when an alarm is active.
Off, One-Shot, Continuous
* The factory default configuration settings are in bold.
To Next Page
