System Dialog System Setup
26 - 12 V Series Operating Instructions
NOTE: Do not connect unapproved devices to the wireless network.
NOTE: Where the monitor is located, the signal strength of other Wi-Fi devices
on the same channel should be no greater than -85 dBm.
NOTE: Where the monitor is located, the signal strength of other Wi-Fi devices
on adjacent channels should be no greater than -50 dBm.
NOTE: The recommended distance between the patient monitor and other
non-Wi-Fi wireless devices, including wireless devices at the frequency
of 2.4GHz (e.g. cellular mobile communication networks, microwave
ovens, interphones, cordless phones and electro-surgical units) is no
less than 20 cm.
26.2.7.2 Configuring IP Address
CAUTION: Disconnecting from the network may result in data loss, including
waveforms, numerics, alarm events, trends and patient data, or
function failure. Check the patient in case of network disconnection
and solve the network problem as soon as possible.
To configure the network settings:
1. Select the Setup tab from the Navigation Area.
2. Select the System button, enter the password, then select the Accept button.
3. Select the Network tab, then select the IP Configuration button.The IP Configuration dialog
displays (as shown in FIGURE 26-7 and FIGURE 26-8).
FIGURE 26-7 Example IP Configuration Dialog for Wired Network
