V Series Operating Instructions 26 - 11
System Setup System Dialog
5. Select the Cancel or Accept button.
•The Cancel button closes the dialog without saving the settings.
•The Accept button saves the settings and closes the dialog.
26.2.7.1 Requirements for Setting Up the Wireless Network
A Mindray proprietary wireless network, installed by approved Mindray service personnel, is required
to support wireless networking.
This proprietary network will have the following capabilities:
• Support the 802.11g wireless protocol
• Have a channel bandwidth of 20 MHz
• Support WPA2-PSK security
• Provide a signal strength at the monitor of no less than -65 dBm
CAUTION: Always set the wireless network according to local wireless regulations.
NOTE: Contact Mindray Service or sales agent for advice on appropriate
configurations and deployment of network devices, including wireless
AP and network switch.
NOTE: Keep network authentication information (e.g, password) safe to
protect the network from being accessed by unauthorized users.
NOTE: Authentication and encryption other than WPA2-PSK may expose
sensitive data leak or malicious setting.
NOTE: The total throughput of all the wireless devices connected to the
wireless network should be less than the effective transmitting
capability of the wireless network. The throughput capacity of a single
V 12/V 21 is about 400 kbps for Panorama CMS.
VAccess Setup Select to enable access to a maximum of four
remote computers.
Refer to "Configuring VAccess" on
page 26-15 for additional
information.
DIAP Baud Rate Select to change the DIAP baud rate of
transfer.
9600, 19200
NOTE: When using DIAP, the VDI module mode
must be configured to DIAP. Refer to
"Changing VDI Modes" on page 5-4 for
additional information.
NOTE: Refer to the DIAP Communications Protocol
Service Manual (P/N 0070-00-0307) for
additional information.
ECG Management Select to access the ECG Management
Setup dialog.
N/A
NOTE: Refer to "Configuring ECG Management
Setup" on page 26-16 for additional
information.
TABLE 26-6
BUTTON/
CHECK BOX DESCRIPTION / COMMENTS CHOICES*
* The factory default configuration settings are in bold.
To Next Page
