System Dialog System Setup
26 - 10 V Series Operating Instructions
26.2.7 Configuring the Network Tab
Select the Network tab to define the hospital name, department, indicate if the monitor will be
networked to another monitor or to a central station, establish VAccess connections, and activate the
ECG management. These functions apply to all patient sizes.
1. Select the Setup tab from the Navigation Area.
2. Select the System button, enter the password, then select the Accept button.
3. Select the Network tab.
The Network tab displays (as shown in FIGURE 26-6).
FIGURE 26-6 Example System Dialog (Network Tab)
4. Select the buttons described in TABLE 26-6 to configure the tab.
TABLE 26-6
BUTTON/
CHECK BOX DESCRIPTION / COMMENTS CHOICES*
Hospital Provides clinician or biomedical engineer a
means to specify the hospital name.
Accepts up to 15 alphanumeric
characters.
Factory defaults to blank.
Department Provides clinician or biomedical engineer a
means to specify the department name.
Accepts up to 15 digital
characters.
Factory defaults to blank.
IP configuration Select to access the IP Configuration dialog. .Refer to "Requirements for Setting
Up the Wireless Network" on page
26-11 for additional information.
NOTE: When the IP address of wired network is
changed, restart the V 12/ V21 to take the
changed IP address into effect.
* The factory default configuration settings are in bold.
