Specifications Product Specifications
29 - 6 V Series Operating Instructions
29.1.4 V Dock Safety Designations:
TABLE 29-4
Type of protection against electric shock: Class I
Supply Connection (Input): 90Vac min - 264 Vac max
47Hz min, 63 Hz max, Single Phase
Supply Connection (Output): 14.3Amps (max), +15Vdc Output
Mode of Operation: Continuous
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids Drip-proof (IPX1)
Degree of electrical connection between
equipment and patient:
Equipment designed for non-electrical connection to the
patient
Degree of Mobility: Portable
Maximum Size: 6.2"H x 7.6"W x 9.9"D
Maximum Weight: 3.5 lbs.
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C
Storage Humidity: 10% to 95%, non-condensing
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1- AC Present
1- Battery(ies) Charging
Interfaces: 1 - V Dock Interface (D1)
3 - V Hub Interface (MR1- MR3)
3 - Serial Bus (SB1-SB3)
1 - Nurse Call (NC1)
1 - Video (DV1)
1 - Ethernet (CS1)
1 - AC Inlet
