V Series Operating Instructions 29 - 7
Product Specifications Specifications
29.1.5 VPS Safety Designations:
TABLE 29-5
Type of protection against electric shock: Class II
Degree of protection against electric shock: ECG - Type CF defibrillation protected
IBP - Type CF defibrillation protected
Temperature - Type CF defibrillation protected
NIBP - Type BF defibrillation protected
SpO
2
-Type BF
Supply Connection: +12VDC, +5VDC from M1 through M6
Mode of Operation: Continuous
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids Drip-proof (IPX1)
Degree of electrical connection between equipment
and patient
Equipment designed for direct electrical and non-
electrical connection to the patient
Degree of Mobility: Portable
Maximum Size: 2.988"H x 6.2"W x 5.5"D
Maximum Weight: 1.95 lbs.
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C.
Storage Humidity: 10% to 95%, non-condensing.
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1- Button, Silence All Alarms
1- Zero All IBPs Button
1- Start/Stop NIBP
1- LED, Powered and Communicating
Interfaces: 1- Non-Invasive Blood Pressure
1 - Temperature
2- Invasive Blood Pressure
1- ECG
1- Nellcor SpO
2
or Masimo SpO
2
2 - Analog Output/Defib Sync
2 - Mx & My Module Bay Connectors
