3-2
NOTE
The environmental specifications of unspecified parameters are the same as those
of the main unit.
3.2.3 Electrical Requirements
Check cables and power cords. Make sure that:
1. Check that the system cables, power cords, and power plugs are not damaged, and that
the pins are not loose. In case of any damage, remove it from use.
2. The insulation of patient cables and leadwires is not damaged, and connectors are not
loose.
WARNING
Only power sockets with protective grounding can be used.
Use the supplied power cord only!
If you doubt the completeness of the installation and cabling of the external
protective cables, disconnect the equipment from the power line and operate it on
battery. Otherwise, patient or operator might be shocked.
Voltage
100 to 240V AC
Current
0.9 to 0.5A
Frequency
50/60 Hz
3.3 Equipment Installation
Follow the procedure below to install the equipment:
1. Check the quantity of equipment and accessories as per the packing list.
2. Check for mechanical damages on the equipment and accessories.
3. Install the battery (optional). For detailed operations, please refer to the Operator's
Manual of the vital signs monitor.
4. Connect AC power.
5. Connect the accessories.
Installation Support
The vital signs monitor can be mounted on a wall bracket or on a trolley support. The wall
bracket or trolley support can be ordered optionally. Each type of mounting bracket is
delivered with a complete set of mounting hardware and instructions. For detailed
installation information, please refer to Wall-mount Bracket Instructions for Use (PN:
0010-20-42933) and Rollstand Instructions for Use (PN: 0010-20-42934).
