7-16
7.1.11.2 Parts List
Note: The P/N of this assembly is 0621-30-69408.
S/N P/N Description Qty
1 0621-20-69422 Tabletop base 1
2 0621-20-69424 Right fixing bracket for tabletop rail 1
3 0621-20-69425 Middle fixing bracket for tabletop rail 1
4 0621-20-69555 Left fixing bracket for tabletop rail 1
5 0621-30-69427 Handle asssembly 1
6 0621-20-69467 Tabletop bracket 1
7 M04-000202--- Plain washer, normal series, product grade A GB/T97.1-20028
rustproof nickel plating
8
8 M04-021031--- Stainless steel single coil spring lock washer,normal type
GB/T93-1987 8
8
9 M04-051119--- Hexagon socket cap head screw GB/T70.1-2000 M8X16
rustproof nickel plating
8
10 0621-20-69421 Tabletop decorative plate (mold MR69421) 1
11 0621-20-69501 φ5 positioning pin 4
12 0621-30-69468 Capacity assembly 1
13 M04-000205--- Stainless steel cross recessed countersunk head screw
GB/T819.2-1997 M4X8 polishing
9
14 M04-005005--- Cross recessed countersunk head screw GB/T819.1-2000
M3X6 rustproof nickel plating
3
15 0621-30-69624 Circuit bracket assembly 1
16 0601-30-69857 Circuit adapter assembly 1
17 M04-002505--- Cross recessed pan head screw GB/T818-2000 M3X6
rustproof nickel plating
4
18 0621-20-69554 Press bar for locking catch base 1
19 M6P-020001--- Locking catch MC-37 white 1
20 0621-30-78580 Tabletop operation console assembly 1
21 M04-051140--- Cross recessed small pan head screw assembly GB/T9074.8
M3X8 rustproof nickel plating
2
22 M04-051139--- Cross recessed small pan head screw assembly GB/T9074.8
M4X12 rustproof plating
16
23 0621-20-69553 Mounting plate for locking catch base 1
24 0621-30-69458 N2O cylinder bracket assembly 1
25 0621-30-69457 O2 cylinder bracket assembly 1
26 M04-051062--- Stainless steel hexagon socket cap head screw GB/T70.1-2000
M5x16 polishing
4
To Next Page
