7-52
S/N P/N Description Qty
11 M04-051106--- SUS316 cross recess head screw GB/T818-2000 M2.5X8
polishing
3
12 M6M-010047--- Seal, O-ring 33.X2.5 silicone A50 red 2
7.2.9 Median Plate Assembly
7.2.9.1 Exploded View
7.2.9.2 Parts List
Note: The P/N of this assembly is 0601-30-78870.
S/N P/N Description Qty
1 0601-20-69777 Lower sealing cushion (mold MR78839) 1
2 0601-20-69776 Upper sealing cushion (mold MR78839) 1
3 0601-20-69871 Median plate 1
To Next Page
