Mindray WATO EX-65 - APL Valve Assembly

7-49
S/N P/N Description Qty
9 0601-20-69896-51 Upper cover (mold MR69896) 1
10 M6M-010069--- Seal, O-ring 3X1.5 fluororubber, A50 black 2
11 0601-30-78872 Bag/mechanical ventilation switch assembly 1
12 M04-021072--- SUS316 plain washer,normal series, product grade A
GB/T97.1-2002 3 polishing
3
13 M04-021067--- SUS316 single coil spring lock washer, normal type
GB/T93-1987 3 polishing
3
14 M04-051118--- SUS316 cross recess head screw GB/T818-2000 M3X10
polishing
3
15 M04-051109--- SUS316 cross recess head screw GB/T818-2000 M3X8
polishing
6
16 M6M-010035--- Seal, O-ring 6.07X1.78 ethylene propylene terpolymer
(EPT), black A70
6
17 0601-20-69870 Check valve bracket 2
18 M6M-010067--- Seal, O-ring 40X2 silicone red A50 2
7.2.7 APL Valve Assembly
7.2.7.1 Exploded View
