7-21
7.1.14.2 Parts List
Note: The P/N of this assembly is 0621-30-69597.
S/N P/N Description Qty
1 M04-000401--- Stainless steel hexagon nut GB/T6170-2000 M4 polishing 3
2 M04-021005--- Single coil spring lock washer, normal type GB/T93-1987 4
rustproof nickel plating
3
3 M04-004702--- Plain washer, normal series, product grade
AGB/T97.1-20024 rustproof nickel plating
6
4 0621-20-69598 Bracket for auxiliary electrical outlet (Euro standard) 1
5 0621-20-69603-51 Overlay for auxiliary electrical outlet (Euro standard 220V) 1
6 509B-10-06194 HEADER fuse holder φ5*20 6
7 0621-20-69609 Cable for Euro standard socket 3
7.1.15 Power Box Assembly
7.1.15.1 Exploded View
