7.1.17.2 Parts List
Note: The P/N of this assembly is 0621-30-78550.
S/N P/N Description Qty
1 M04-051115---
Stainless steel hexagon socket cap head screw
GB/T70.1-2000 M5X20 4
2 0010-20-42769 Bracket slide block 1
3 M04-051141---
Cross recessed small pan head screw assembly
GB/T9074.8 M4X8 rustproof nickel plating 3
4 0621-20-69581 Mounting plate 1
5 M04-005005---
Cross recessed countersunk head screw
GB/T819.1-2000 M3X6 rustproof nickel plating 6
6 0621-20-69577-51 Bottom plate 1
7 M04-051045---
Cross recessed small pan head screw
GB/T823-1988 M2.5X6 rustproof nickel plating 4
8 0010-20-42983 Locking knob 1
9 0621-20-69579 Harddisk fixed bar 2
10 0000-10-11065 Harddisk 40GB 5400rpm ATA100 notebook 1
11 M04-051158---
Cross recessed small pan head screw assembly
GB/T9074.8 M3X6 rustproof nickel plating 8
12 0621-30-78747 Main control board assembly 1
13 0621-20-69615 Shielding can 1
14 M04-011002---
Hexagon nut conical lock washer assembly M3
rustproof nickel plating 12
15 M04-051140---
Cross recessed small pan head screw assembly
GB/T9074.8 M3X8 rustproof nickel plating 14
16 0611-30-58810 Button board 1
17 0611-20-58799 Press bar for silicone button 1
18 0611-20-58798-51 Silicone button-51 1
19 0611-20-58800 Fixed plate for silicone button 1
20 0621-20-69578-51 Cover plate 1
21 M04-051016-00
Cross recessed countersunk head screw
GB/T819.1-2000 M3X15 rustproof nickel plating 4
22 9201-20-35962 Mounting plate for fan 1
23 0621-20-78572 CIS fan and fan cable 1
24 M04-000301---
Stainless hexagon nut GB/T6170-2000 M3
polishing 4
25 0611-20-58807 Fan cushion 1
