When available, this selection will automatically take the user
to the special test screen where the test group menu will be
displayed. Make a selection to enter the test, then follow the
on-screen prompts. Mode 8 will not be supported on all
vehicles. If you wish to run an EVAP test on a vehicle that
does not support Mode 8, enter vehicle specic mode and
refer to the Special Tests section on how to run a special test.
Special Tests Button Denitions
Help
View Help
Selecting View Help will open an online user manual.
Screen Capture
Screen Capture
Selecting Screen Capture will save a copy of the current
open screen.
Vehicle Info
Mode 9 views Vehicle Identication Numbers (VINs),
calibration ID(s), and verication number(s).
1. Select Vehicle Info from the Generic OBDII screen.
2. Follow the prompts on the screen.
The 17 digit VIN provides information on the vehicle including
year of manufacture, engine and possibly transmission type,
vehicle body style, and color. Mode 9 is not supported on older
vehicles, so a visual check of the VIN through the windshield or
on the door sticker would be required to obtain that VIN. Mode 9
is used on the tool to AutoID the vehicle and for calibration
verication to see if a newer calibration is available for re-ashing
the ECU.
Vehicle Info Button Denitions
Help
Help
Selecting Help will open an online user manual.
Use Metric Units
Use Metric Units
Selecting Metric Units will switch from English/Standard
Units to Metric Units.
Use English/Standard Units
Use English/Standard Units
Selecting English/Standard Units will switch from Metric
Units to English/Standard Units.
