Mitchell Diagnostics MD-500 - General Information and Device Overview; Introduction

en-US
|
4
| User Manual |
MD-500
1699503426 | REV A | 05.2021
© Mitchell International
General Information
Introduction
Connected
Generic OBDII
Repair-Source
10:22
QuickScan
Apps Shortcut
Settings
What’s New
Web Browser Coverage Guide Video Tutorials
Diagnostic Information Wiring Diagrams
i
i
Saved Reports
Main Menu
Diagnostics
1
2
3
8
11
10
9
4
5 6
7
12
1. Front facing camera
2. Vehicle connection indicator
3. VCI connection manager
4. Power button
5. Volume up button
6. Volume down button
7. USB C charging/data port
8. Main Menu functions
9. Back button
10. Home button
11. Recent app button
12. Docking station connector
