12
S
PECIFICATIONS
CHAPTER 2 ABOUT EX CONTROLLER
3 Ready Green steady on All lines are enabled (operational
state).
Green steady off All lines are disabled (operational
state).
Green blinking
1 cycle per 4 seconds,
75% duty
At least one line is enabled and at
least one line is disabled (operational
state).
5 In-Use Off Lines are idled and unlocked.
Yellow steady on Lines are in use and unlocked.
Yellow blinking
1 cycle per second,
50% duty
Locked
10 Link Green steady on Indicates that the PRI port is
connected, and the link is up.
Off Indicates that the PRI port is not
connected, and the link is down.
10 In-Use Amber steady ON Indicates that the PRI port is
connected.
Off Indicates that the PRI port is not
connected.
10 Error/Trouble Red, steady ON Indicates that the PRI port is not
working properly.
Off Indicates that the PRI port is working
properly.
11 Ready Amber steady ON Indicates that the DSP card is ready
to send and receive calls.
Off Indicates that the DSP card is not
connected.
13 ETH1 - Right LED
(activity)
Green blinking,
variable rate
Connected with active network traffic.
Green steady on Connected with no network traffic.
Off Not connected
Table 2.1: (Continued) (Sheet 2 of 3)
# LED LED State Description
