13
S
PECIFICATIONS
CHAPTER 2 ABOUT EX CONTROLLER
13 ETH1 -Left LED
(speed)
Off 10 Mbps
Green 100 Mbps
Yellow 1000 Mbps
14 ETH2/3/4/5/ext -Right
LED (activity)
Green blinking,
variable rate
Connected with active network traffic.
Green, steady on Connected with no active network
traffic.
Off Not connected
14 ETH2/3/4/5/ext -Left
LED (speed)
Off 10 Mbps
Green 100 Mbps
Yellow 1000 Mbps
Table 2.2:
# SWITCH DESCRIPTION
4 Reset/Default Pressing Duration Result LED Pattern
2 to 6 seconds Restarts the EX
Controller unit.
Power LED blinking.
All other LEDs are
off.
7 to 11 seconds Initiates a Partial
Reset of the EX
Controller unit.
All LEDs blinking
one cycle per
second, 50% duty.
12 to 16 seconds Initiates a Factory
Reset of the EX
Controller unit.
All LEDs steady on.
17 seconds or more No action taken.
NOTE: A useful
option if you have
accidentally pushed
the button and do
not want any action
to be performed.
All LEDs will turn off
after blinking and
turn steady on.
Table 2.1: (Continued) (Sheet 3 of 3)
# LED LED State Description
