14.5.5. Power
The following data concerning robot controller’s main circuit power supply can be monitored.
- Motor power voltage
A present power-supply voltage value is displayed.
- Motor power voltage (MAX)
The maximum value of the motor power voltage in servo ON is displayed.
- Motor power voltage (MIN)
The minimum value of the motor power voltage in servo ON is displayed.
- Regeneration level
The regenerative current value of each axis is displayed as an alarm level.
The excessive regeneration error occurs when this value reaches 100%.
Click [Reset] button to reset all Servo Monitor.
Figure 14-55 Servo monitor - Power
