910
APPX
Appendix 9 Processing Time
■Memory dump function
The execution of the memory dump function results in an increase in the scan time. The increase in scan time can be
calculated by the following formula.
Increase in scan time [s] = (KM1  Number of points
*1
) + KM2
*1 This indicates the total number of points (total number of words) of devices that are set in the device area, file storage area, and refresh
data register area. (unit: K words).
■Real-time monitor function
The execution of the real-time monitor function results in an increase in the scan time. The increase in scan time can be
calculated by the following formula.
Increase in scan time [s] = KM1 + (KM2  Number of points of word device) + (KM3  Number of points of bit device)
• In monitoring global devices (X, Y, M, L, B, F, SB, V, T, ST, C, LT, LST, LC, D, W, SW, FX, FY, SM, FD, SD, BLn\S)/global
labels
• In monitoring file registers (R, ZR)
• In monitoring module access devices (Un\G, U3En\G, U3En\HG)/link direct devices (Jn\W, Jn\X, Jn\SW, Jn\Y, Jn\SB, Jn\B)
• In monitoring local devices (M, V, T, ST, C, LT, LST, LC, D)/local labels
Constant Setting of the internal buffer capacity Constant value
KM1 32K bytes 0.70
256K bytes 4.70
3040K bytes 40.00
KM2 32K bytes 320.00
256K bytes 2290.00
3040K bytes 16400.00
Constant Constant value
KM1 149.00
KM2 3.20
KM3 0.80
Constant Constant value
KM1 149.00
KM2 3.50
KM3 1.10
Constant Constant value
R00/R01/R02CPU Other CPU modules
KM1 180.00 156.00
KM2 11.30 11.60
KM3 12.80 8.90
Constant Constant value
R00/R01/R02CPU Other CPU modules
KM1 149.00 149.00
KM2 8.80 6.20
KM3 5.80 3.10
