The monitors/tests debug the positioning operation.
Caution
When the communication error due to the forced termination of FX Configurator-FP, peripheral devices'
power OFF and the connection cable unplugging occurs, all axis stops.
1) Operate any of the following procedures when turning OFF m code while monitoring/testing.
- Click [m code off X-axis] / [m code off Y-axis].
- Click [Online]  [Test]  [m code off]  [m code off X-axis] / [m code off Y-axis].
2) Operate any of the following procedures when suspending all axis in operation due to peripheral the
devices' error, etc. while monitoring/testing.
- Click [All axis stop command].
- Click [Online]  [Test]  [All axis stop].
STARTUP AND MAINTENANCE
PRECAUTIONS
• Do not touch any terminal while the PLC's power is on.
Doing so may cause electrical shock or malfunctions.
• Before cleaning or retightening terminals, externally cut off all phases of the power supply.
Failure to do so may expose you to shock hazard.
• Before modifying the program under operation or performing operation for forcible output, running or stopping,
carefully read the manual, and sufficiently ensure the safety.
An operation error may damage the machine or cause accidents.
• To test Zero-return, JOG operation and Positioning data, throughly read this manual, ensure the safe system
operation
An operation error may damage the machine or cause accidents.
The response, such as the JOG operation, may be slow according to the running state of the personal computer at
the time of the test operation. In the test operation, the PLC performance can be slower due to the busy state of
personal computer.
- End all other applications running except FX Configurator-FP.
- At destination specification (refer to chapter 6), set the transmission speed at 38.4kbps or higher.
STARTUP AND MAINTENANCE
PRECAUTIONS
• Do not disassemble or modify the PLC.
Doing so may cause failures, malfunctions or fire.
For repair, contact your local Mitsubishi Electric distributor.
• Before connecting or disconnecting any extension cable, turn off power.
Failure to do so may cause unit failure or malfunctions.
• Before attaching or detaching the following devices, turn off power.
Failure to do so may cause device failure or malfunctions.
- Peripheral devices, expansion boards and special adapters
- I/O extension blocks/units and terminal blocks
