Mitsubishi FX3U Series Operation Manual

1 Introduction
1.3 System Configuration
17
FX Configurator-FP
Operation Manual
1
Introduction
2
Install Uninstall Start&Exit
3
Window and Operation Config
4
Creating Files
5
Data set
6
Setting The Connection
7
Data flow And Procedure
8
Debug In the Positioning
9
Print
10
Edit Function In data
1.3.2 Applicable models
•FX3U-20SSC-H type positioning module
• Servo amplifier, applicable to SSCNET III (up to 2pcs)
Connect these servo amplifiers to the FX
3U-20SSC-H via SSCNET .
1.3.3 Operating System Requirements
Item Description
OS
32 bit version
•Microsoft

Windows

95 English version (Service Pack 1 or later)
•Microsoft

Windows

98 English version
•Microsoft

Windows

Millennium Edition English version
•Microsoft

WindowsNT

4.0 Workstation English version (Service Pack 3 or later)
•Microsoft

Windows

2000 professional English version
•Microsoft

Windows

XP English version (Home Edition or Professional)
•Microsoft

Windows Vista

English version (Home Basic, Home Premium, Business,
Ultimate or Enterprise)
*1
•Microsoft

Windows

7 English version (Ultimate, Enterprise, Professional, Home
Premium or Starter)
*2
•Microsoft

Windows

8 English version (8, Pro, Enterprise)
*3
•Microsoft

Windows

8.1 English version (8.1, Pro, Enterprise)
*3
•Microsoft

Windows

10 English version (Home, Pro, Enterprise, Education)
*3
64 bit version
•Microsoft

Windows

7 English version (Ultimate, Enterprise, Professional or Home
Premium)
*2
•Microsoft

Windows

8 English version (8, Pro, Enterprise)
*3
•Microsoft

Windows

8.1 English version (8.1, Pro, Enterprise)
*3
•Microsoft

Windows

10 English version (Home, Pro, Enterprise, Education)
*3
PC main body
•Microsoft

Windows

95:
CPU Pentium 133MHz or higher
•Microsoft

Windows

98:
CPU Pentium 133MHz or higher
•Microsoft

Windows

Millennium Edition:
CPU Pentium 150MHz or higher
•Microsoft

WindowsNT

4.0:
CPU Pentium 133MHz or higher
•Microsoft

Windows

2000:
CPU Pentium 133MHz or higher
•Microsoft

Windows

XP:
CPU Pentium 300MHz or higher
•Microsoft

Windows Vista

:
CPU Pentium 1GHz or higher
•Microsoft

Windows

7:
CPU Pentium 1GHz or higher
•Microsoft

Windows

8:
CPU Pentium 1GHz or higher
•Microsoft

Windows

8.1:
CPU Pentium 1GHz or higher
•Microsoft

Windows

10:
CPU Pentium 1GHz or higher
