8 Debug in the positioning
8.2 Testing the Operation
84
FX Configurator-FP
Operation Manual
*1. For the user unit, refer to the following.
*2. Available at X-axis operation test only.
Refer to Section 5.1.
4 Click <RVS JOG>, <FWD JOG> or <Setup>.
1. <RVS JOG>
20SSC-H executes the reverse JOG operation at the specified JOG speed and JOG instruction evaluation
time.
2. <FWD JOG>
20SSC-H executes the forward JOG operation at the specified JOG speed and JOG instruction evaluation
time.
3. <Setup>
FX Configurator-FP sets the MPG Enable flag and manual pulse input magnification (numerator/
denominator).
Item Description
Monitor item
Displays present address, Operation speed present value, status information and Error
code
Present address
Displays the present address [Unit : User unit
*1
]
Operation speed present
value
Displays the operation speed present value [Unit : User unit
*1
]
READY/BUSY
Displays status information
• READY: ON
•BUSY: OFF
Error code
Displays error codes
Displays 0 with no error
JOG operation Executes the JOG at the specified JOG speed and JOG instruction evaluation time
JOG speed
Sets the JOG speed in 20SSC-H positioning parameter
Setting range : 1 to Maximum speed [User unit
*1
]
Set the value within 1 to 50,000,000Hz in the converted pulse data.
JOG instruction
evaluation time
Sets the JOG instruction evaluation time in 20SSC-H positioning parameter
Setting range : 0 to 5000ms
Start using acceleration
and deceleration time 2
Starts using with acceleration and deceleration time 2.
<RVS JOG> Executes reverse JOG while held
<FWD JOG> Executes forward JOG while held
Manual pulse operation Sets the MPG operation
MPG input selection
*2
Sets the MPG input selection
0: X input - X opr / Y input - Y opr
1: X input / Y opr
2: X input - X and Y opr
Manual pulse input
magnification
Sets the manual pulse input magnification (numerator/denominator)
Setting range : (Numerator) 1 to 1,000,000
(Denominator) 1 to 1,000,000
MPG response
Sets the MPG response
Setting range : 1 to 32767
MPG Enable flag Enables the MPG operation when ticked off
<Setup>
Sets the MPG Enable flag and manual pulse input magnification (numerator/
denominator)
<All axis stop> Stops all axis
<Stop> Stops the axis in operation test
<Close> Cancels the setting, and closes the dialog box
