ENGINE EMISSION CONTROL –
Engine Control System /
Emission Control System <MPI>
17-2
ENGINE CONTROL SYSTEM
SERVICE SPECIFICATIONS
Items Standard value
Idle speed rpm 850 ± 50
EMISSION CONTROL SYSTEM <MPI>
ON-VEHICLE SERVICE
SYSTEM CONFIGURATION DIAGRAM
Canister
Check
valve
Throttle body
Fuel pressure control
valve
Fuel pressure regulator
PCV valve
Air
Injector
High temperature sensor*
*: EVOLUTION-IV only
