BASIC BRAKE SYSTEM – Disc Brake
35A-9
DISC BRAKE
<EVOLUTION-VI WITH BREMBO BRAKING SYSTEM>
DISASSEMBLY AND REASSEMBLY
Front Brake
Seal & boot kit Shim set
Clip set Pad set
Brake caliper kit
1
2
3
4
5
6
7
8
9
10
1
2
3
4
3
4
1
2
5
6
5
5
7
9
9
7
9
7
8
6
6
10
2
1
Disassembly steps
1. Pin
2. Cross spring
3. Pad & wear indicator assembly
4. Pad assembly
5. Shim
6. Air bleeder screw
7. Piston boot
8. Piston
9. Piston seal
10. Caliper body
