EXTERIOR – Aero Parts <EVOLUTION-IV>
51-7
AERO PARTS <EVOLUTION-IV>
REMOVAL AND INSTALLATION
1
2
3
4
5
6
Insert bolt mounting locations
Double-sided adhesive tape:
SUMITOMO 3M 4211 or equivalent (width: 5 mm)
Primer: SUMITOMO 3M C100 or equivalent
3
2
5
6
2
5
4
Front air dam removal steps
1. Front air dam center
2. Front air dam
3. Brake duct
Side air dam removal
AA""AA 4. Side air dam
Rear air dam removal steps
5. Rear air dam
6. Rear air dam center
NOTE
The conventional service points apply for removal and
installation.
