Body Dimension
42-10
69
11
indicates that the dimension and the measurement point are the same as those for EVOLUTION-IV.
Unit: mm
13
12
2
21
22
20
65
1,199
103
812
842
920
312
116
275
1,068
No. Standard measurement point Hole _ Size
shape mm
No. Standard measurement point Hole _ Size
shape mm
11
Center of strut insulator f – 110
65
Trailing arm mounting position –
12
Center of suspension crossmember mounting hole f – 15
69
Center of rear shock absorber mounting hole f – 68
13
Center of suspension crossmember mounting hole f – 16
70
Control link mounting position –
20
Differential mounting bolt end –
71
Center of upper link mounting hole f – 14
21
Center of suspension crossmember mounting hole f – 14
72
Center of upper link mounting hole f – 14
22
Center of suspension crossmember mounting hole
Left: f – 13.5
Right: – 12.2 × 14
