EXTERIOR – Water Spray <EVOLUTION-IV>
51-12
WATER SPRAY <EVOLUTION-IV>
REMOVAL AND INSTALLATION
1
2
3
4
5
6
6
1. Water spray switch
Removal steps
D Front bumper (Refer to P.51-3.)
2. Washer tank
3. Washer motor
4. Water spray motor
5. Water spray hose
6. Water spray nozzle
INSPECTION
WATER SPRAY SWITCH CONTINUITY CHECK
Switch position Terminal No.
1 2
ON
OFF
