EXTERIOR – Mark <EVOLUTION-V>
51-16
2. brembo MARK
Application tape edge
Rear bumper line
Trunk lid opening line
3. EVOLUTION-V MARK (REAR)
Trunk lid opening line
Rear bumper line
(2) Installation procedure
1. Using unleaded gasoline, degrease the surface of the body on which the marks are mounted.
2. Peel off the release paper from the back side of the mark and affix the mark, ensuring the specified
dimensions are met.
Caution
(1) Perform the procedure in a dust-free place with an ambient temperature ranging from
20 to 38_C.
(2) If the ambient temperature is below 20_C, heat the mark and mounting position to 20
to 30_C.
(3) Be sure to press each mark positively, as a low pressure results in the mark being
separated easily.
To Next Page
