MPI – Troubleshooting
13-51
INSPECTION PROCEDURE 43
MUT-II: Check if hesitation, sag, stumble or poor acceleration occurs.
OK
MUT-II Data list
26 Idle position switch (Refer to P.13-58.)
NG
Check the idle position switch system.
(Refer to P.13-38, INSPECTION PROCEDURE 26.)
OK
MUT-II Data list
13 Intake air temperature sensor (Refer to P.13-56.)
NG
Check the intake air temperature sensor system. (Refer to P.13-9,
INSPECTION PROCEDURE FOR DIAGNOSIS CODE 13.)
OK
MUT-II Data list
25 Barometric pressure sensor (Refer to P.13-58.)
NG
Check the barometric pressure sensor system. (Refer to P.13-14,
INSPECTION PROCEDURE FOR DIAGNOSIS CODE 25.)
OK
MUT-II Data list
21 Engine coolant temperature sensor (Refer to P.13-57.)
NG
Check the engine coolant temperature sensor system.
(Refer to P.13-10, INSPECTION PROCEDURE FOR DIAGNOSIS
CODE 21.)
OK
MUT-II Data list
14 Throttle position sensor (Refer to P.13-57.)
NG
Check the throttle position sensor system. (Refer to P.13-9, IN-
SPECTION PROCEDURE FOR DIAGNOSIS CODE 14.)
OK
MUT-II Actuator test
12 Waste gate solenoid valve (Refer to P.13-61.)
NG
Check the waste gate solenoid valve system.
(Refer to P.13-45, INSPECTION PROCEDURE 35.)
OK
MUT-II Data list
11 Oxygen sensor
OK: Changes between 600–1,000 mV during sudden racing
NG
Check the oxygen sensor system. (Refer to P.13-42, INSPECTION
PROCEDURE 31.)
OK
MUT-II Data list
11 Oxygen sensor
OK: Changes between 0–400 mV and 600–1,000 mV during
idling
NG
Check the fuel pressure. (Refer to P.13-30.)*
OK
MUT-II Actuator test
09 Fuel pressure control valve (Refer to P.13-61.)
NG
Check the fuel pressure control valve system.
(Refer to P.13-45, INSPECTION PROCEDURE 34.)
1. Inspect the intake of air into the air intake system
D Broken intake manifold gasket
D Broken vacuum hose
D PCV valve does not operate.
D Broken air intake hose
2. Check the injector for clog.
NOTE
*: Refer to Workshop Manual for LANCER EVOLUTION-IV and EVOLUTION-V (Pub. No. S9806CNCP9).
To Next Page
