EXTERIOR – Front Bumper / Aero Parts
51-4
DISASSEMBLY SERVICE POINT
AA" CLIP REMOVAL
1. Use the special tool to pull up the center pin in the clip.
2. Remove the clip.
AERO PARTS
REMOVAL AND INSTALLATION
2
1
Front airdam removal steps
1. Air blow duct
AA""AA 2. Front airdam
NOTE
The removal and installation service points for the new model
are the same as those for the preceding models.
Pin
Clip
MB990784
MB990784
