ENGINE – Secondary Air System and Intake Manifold
11-29
SECONDARY AIR SYSTEM AND INTAKE MANIFOLD
REMOVAL AND INSTALLATION
1
2
3
4
5
6
7
8
9
10
11
11 Nm
35 Nm
24 Nm
11 Nm
19 Nm
30 Nm
35 Nm
24 Nm
49 Nm
21 Nm
13 Nm
21 Nm
35 Nm
Removal steps
1. Exhaust manifold heat protector
2. Vacuum hose and vacuum pipe
"BA 3. Air pipe assembly
4. Air control valve gasket
5. Air control valve assembly
6. Engine hanger
"AA 7. Air control valve bracket
8. Intake manifold stay
9. Alternator brace stay
10. Intake manifold
11. Intake manifold gasket
