SRS – Troubleshooting
52B-7
INSPECTION PROCEDURE CLASSIFIED BY DIAGNOSIS CODE
Code No.14 Analog G-sensor system in the SRS-ECU Probable cause
The SRS-ECU monitors the output of the analog G-sensor inside the SRS-ECU.
It outputs this code when any of the following are detected.
D When the analog G-sensor is not operating
D When the characteristics of the analog G-sensor are abnormal
D When the output from the analog G-sensor is abnormal
D Malfunction of SRS-ECU
Replace the SRS-ECU.
Code No.15, 16 Safing G-sensor system in the SRS-ECU Probable cause
This code is output if there is a short or open circuit between the terminals of the
safing G-sensor inside the SRS-ECU.
The trouble causes for each diagnosis code No. are as follows.
D Malfunction of SRS-ECU
Code No. Trouble symptom
15 Short circuit in the safing G-sensor
16 Open circuit in the safing G-sensor
Replace the SRS-ECU.
To Next Page
