12.7 Special Register List
12 - 73
12
TROUBLESHOOTING
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
Remark
*3 : Extensions are shown in Table12.20.
Table12.19 Special register
Number Name Meaning Explanation
Set by
(When set)
Corresponding
CPU
SD5
Error
common
information
Error common
information
• Common information corresponding to the error codes (SD0)
is stored here.
• The following six types of information are stored here:
1) Module No./Base No.
*1: The storing value "255" in SD5 (Slot No.) indicates that the
slot number for a module specified by an instruction cannot
be identified. When storing the base number to SD5, store 0
(main base unit).
*2: The storing value "FFFFH" in SD6 (I/O No.) indicates that the
I/O number cannot be identified on the I/O assignment setting
tab of PLC parameter due to overlapping of I/O numbers or
that the I/O number cannot be identified from the network
number specified by an instruction. In this case, the error
location can be identified in SD5.
2) File name/Drive name
S (Error) QS
SD6
SD7
SD8
SD9
SD10
SD11
SD12
SD13
SD14
SD15
Table12.20 Extension name
SDn SDn+1
Extension
name
File type
Higher 8 bits Lower 8 bits Higher 8 bits
51H 50H 41H QPA
Parameters
51H 50H 47H QPG
Sequence program
51H 43H 44H QCD
Device comment
1
SD5
SD6
SD7
SD8
SD9
SD10
SD11
SD12
SD13
SD14
SD15
Number
Slot No./Base No.
I/O No. 2
Meaning
(Empty)
SD5
SD6
SD7
SD8
SD9
SD10
SD11
SD12
SD13
SD14
SD15
2E
H(.)
3
Number Meaning
Drive
File name
(ASCII code: 8 characters)
Extension
(ASCII code: 3 characters)
(Empty)
MAIN.QPG
41H(A) 40H(M)
43H(N) 49H(I)
20
H( SP )20x( SP )
20
H( SP )20H( SP )
51H(Q) 2EH(.)
47
H(G) 50H(P)
b15 to b8 b7 to b0
(Example) File name =

Mitsubishi MELSEC Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	MELSEC
Programming Languages	Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
Communication Protocols	Ethernet, CC-Link, RS-232, RS-485, USB, Profibus, Modbus
Model Series	FX, Q, L, iQ-R, iQ-F
Input Voltage	100-240V AC, 24V DC (varies by model)
Memory Capacity	Varies widely depending on the CPU module and series. Ranges from kilobytes to megabytes.
I/O Points	16 to 8192 points (varies by model)
Communication Ports	Ethernet, RS-232, RS-485, USB (varies by model)
Programming Software	GX Works2, GX Works3, GX Developer
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 75°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	10 to 57Hz, 0.075mm amplitude; 57 to 150Hz, 9.8m/s² acceleration
Shock Resistance	147m/s², 3 times in each direction (X, Y, Z)
Protection Class	IP20 (varies by model)
CPU Processing Speed	0.02μs to 0.1μs per instruction (varies by model)
