(2) Module mounting orientation
• Install the PLC in the orientation in Figure 10.14 to ensure good ventilation for
heat release.
• Do not mount it in either of the orientations shown in Figure 10.15.
Figure 10.14 Orientation in which modules can be mounted
Figure 10.15 Orientation in which modules cannot be mounted
Vertical mounting Horizontal installation
Horizontal mounting
