Mitsubishi QJ71BR11 User Manual

App - 13 App - 13
MELSEC-Q
APPENDIX
Table 2 Link special Register (SW) List (Continued)
Use permitted/prohibited
Control
station
Normal
station
Remote
master
station
Remote I/O
station
No. Name Description
Optical Coaxial Optical Coaxial Optical Coaxial Optical Coaxial
Indicates the processing result of the ZNWR instruction.
0 : Normal completionZNWR instruction
processing result
Other than 0 : Abnormal completion (see the error codes in
Section 8.3)
Indicates the processing results of the SEND/RECV/READ/
WRITE/REQ/RECVS/RRUN/RSTOP/RTMRD/RTMWR/REMFR/
REMTO instructions (when physical channel 2 is used).
0 : Normal completion
SW0033
(51)
Send/receive instruction
(2) processing result
Other than 0 : Abnormal completion (see the error codes in
Section 8.3)
Indicates the processing results of the SEND/RECV/READ/
WRITE/REQ/RECVS/RRUN/RSTOP/RTMRD/RTMWR/REMFR/
REMTO instructions (when physical channel 3 is used).
0 : Normal completion
SW0035
(53)
Send/receive instruction
(3) processing result
Other than 0 : Abnormal completion (see the error codes in
Section 8.3)
Indicates the processing results of the SEND/RECV/READ/WRITE/
REQ/RECVS/RRUN/RSTOP/RTMRD/RTMWR/REMFR/REMTO
instructions (when physical channel 4 is used).
0 : Normal completion
SW0037
(55)
Send/receive instruction
(4) processing result
Other than 0 : Abnormal completion (see the error codes in
Section 8.3)
Indicates the processing results of the SEND/RECV/READ/WRITE/
REQ/RECVS/RRUN/RSTOP/RTMRD/RTMWR/REMFR/REMTO
instructions (when physical channel 5 is used).
0 : Normal completion
SW0039
(57)
Send/receive instruction
(5) processing result
Other than 0 : Abnormal completion (see the error codes in
Section 8.3)
Indicates the processing results of the SEND/RECV/READ/WRITE/
REQ/RECVS/RRUN/RSTOP/RTMRD/RTMWR/REMFR/REMTO
instructions (when physical channel 6 is used).
0 : Normal completion
SW003B
(59)
Send/receive instruction
(6) processing result
Other than 0 : Abnormal completion (see the error codes in
Section 8.3)
Indicates the processing results of the SEND/RECV/READ/WRITE/
REQ/RECVS/RRUN/RSTOP/RTMRD/RTMWR/REMFR/REMTO
instructions (when physical channel 7 is used).
0 : Normal completion
SW003D
(61)
Send/receive instruction
(7) processing result
Other than 0 : Abnormal completion (see the error codes in
Section 8.3)
Indicates the processing results of the SEND/RECV/READ/WRITE/
REQ/RECVS/RRUN/RSTOP/RTMRD/RTMWR/REMFR/REMTO
instructions (when physical channel 8 is used).
0 : Normal completion
SW003F
(63)
Send/receive instruction
(8) processing result
Other than 0 : Abnormal completion (see the error codes in
Section 8.3)
SW0040
(64)
Network No.
Stores the network number of the host.
Range: 1 to 239
Stores the group number of the host.
0 : No group designation
SW0041
(65)
Group No.
1 to 32 : Group No.
SW0042
(66)
Station No.
Stores the station number of the host.
Range: 1 to 64 (remote master station: 7D
H
)
Stores the mode status of the host.
0: Online
2 : Offline
SW0043
(67)
Mode status
3 or more : Applicable test
