1 Before Using This Product
No. 99MAF029B
1.3.3 Moving the Main Unit
When moving the main unit on the surface plate, grab the base with your right hand and the carrier
grip with your left hand.
For QMH-600B/QMH-350B/QMH-24"B/QMH-14"B, pressing the air-float switch on the tip of the carrier
grip causes air to make the main unit float, allowing you to move it smoothly above the surface plate.
NOTE
Do not move the product by grabbing parts other than the base or carrier grip. Doing so can negatively
affect measurement accuracy and the product itself.
NOTE
If using the air-float function:
• Measuring with the air-float function active can cause measurement errors.
• Clean the surface plate in advance.
• Use a surface plate of Class JIS1 or higher. If the surface plate is scratched or uneven, the specified
performance may not be achieved.
• Use a rigid surface plate. If the surface plate warps under the weight of the product, the product
may not float.
