55
5 Specifications
No. 99MAF029B
5
Specifications
5.1
Basic Specifications
Code No. Metric 518-230 518-232 518-234 518-236
Inch/Metric 518-231 518-233 518-235 518-237
Model
number
Metric QMH-350A QMH-600A QMH-350B QMH-600B
Inch/Metric QMH-14"A QMH-24"A QMH-14"B QMH-24"B
Measuring range (Stroke) 0 to 465 mm
(350 mm/14")
0 to 715 mm
(600 mm/24")
0 to 465 mm
(350 mm/14")
0 to 715 mm
(600 mm/24")
Resolution Metric 0.001 mm / 0.005 mm
Inch/Metric 0.001 mm / 0.005 mm / 0.00005" / 0.0001" / 0.0002"
Accuracy
(20 C)
Indication
accuracy
*1
±
(2.4 + 2.1 L/600) µm
Repeatability
*1
2
σ
≤
1.8 µm
Perpendicularity (forward
and backward direction)
*2
(20 C)
7 µm 12 µm 7 µm 12 µm
Guiding method Roller bearing
Driving method Manual (wheel drive)
Detection method Electromagnetic induction absolute encoder
Measuring force 1.5
±
0.5 N
Data output Digimatic output / USB
*3
Air-float
N/A
Available (only for the purpose of
moving the unit)
*4
Power supply AA alkaline batteries x 4 (included), AC adapter (optional),
rechargeable nickel-hydride batteries x 4 are supported
*5
Estimated battery life
*6
When the LED is not set to
constantly lit
About 300 hours (continuous use)
About 20 days (regular use: 5 hrs/
day)
LED not set to constantly lit and the
air-float used for half an hour per day
About 80 hours (continuous use)
About 3.3 days (regular use: 5 hrs/
day)
LED constantly lit
About 100 hours (continuous use)
About 13.5 days (regular use: 5 hrs/
day)
If the LED is constantly lit and the
air-float function is used, the battery
life will be reduced to about 2/3 of
the above value.
If the air-float function is not used on air-float equipped models, the battery
life will be approximately the same as models without the air-float function.
If the constant LED or air-float functions will be frequently used, the
optional AC adapter is recommended.
Mass (kg) 25 kg 29 kg 25 kg 29 kg
Dimensions (mm)
QMH-350A/QMH-350B/QMH-14"A/QMH-14"B: 280 (W) x 273 (D) x 784 (H)
QMH-600A/QMH-600B/QMH-24"A/QMH-24"B: 280 (W) x 273 (D) x 1016 (H)
Operating temperature
range (recommended)
0 to 40 C (10 to 30 C)
To Next Page
