61
5 Specifications
No. 99MAF029B
5.5
Optional Accessories
Part No. Accessory name
y
Depth measuring probe
12AAC072 Depth probe
y
Interchangeable contact point for ø5 stepped probe
957261 ø2 ball contact point (coaxial type)
957262 ø3 ball contact point (coaxial type)
957263 ø4 ball contact point (coaxial type)
957264 ø14 disk contact point
957265 ø20 disk contact point
12AAA788 ø4 ball contact point (eccentric type)
12AAA789 ø6 ball contact point (eccentric type)
y
Special holder, special probe
12AAA792 Holder for dial gauge
12AAA793 Long holder
y
AC adapter
06AEG180JA AD620JA (for Japan/U.S.)
06AEG180D AD620D (for EU)
06AEG180E AD620E (for England)
06AEG180K AD620K (for Korea)
06AEG180DC AD620DC (for China)
y
Digimatic connection cable
936937 1 m
965014 2 m
y
Others
05HZA143 9 x 9 adapter (the following clamp is required)
05GZA033 Clamp (for 9 x 9 adapter)
05HZA144 6.35 x 12.7 adapter (the following clamp is required)
901385 Clamp (for 6.35 x 12.7 adapter)
02AZE990 U-WAVE mounting plate
05HZA173 Scriber
*1
*1
The scriber is used for making measurements. It cannot be used for markings.
NOTE
The gauge blocks may be required for zero-setting depending on the probes and contact points to be
used.
