28
2 Basic Measuring Methods
No. 99MAF600B
3 Repeatedly move the ball left and right.
» The value displayed on the
LCD screen will change based
on the vertical movement of
the ball.
4 When the displayed value stops chang-
ing, press .
» The measurement of the high-
est point is complete.
5 If you have tightened the clamp screw,
loosen it.
4
Conrm the measurement.
Tips
• If the product is connected to any external devices, the measurement results will be automatically output. For
details, "3.9 Outputting Measurement Results to an External Device" (page 47)
• The value next to [ZP] displayed in the bottom row of the LCD screen shows the difference between 2 mea-
surements. For details,
"3.1 Calculating the Difference Between 2 Measurements" (page 31)
5
To continue measuring press ; to nish measuring press .
To Next Page
