Page 45
• MAX. Brings all assigned lighting levels gradually to the
maximum level. Tapping the button twice brings all
assigned lighting levels immediately to the maximum level,
bypassing the fade time. This button can be programmed
for custom lighting levels, for example, reducing the
maximum light level to conserve energy, or providing
longer lamp life.
•
OFF. Brings all lighting levels gradually to the minimum
level (the default value is no light). Tapping the button
twice brings all assigned lighting levels immediately to the
minimum level, bypassing the fade time. This button can
be programmed for custom lighting levels, for example,
keeping a minimum light level for safety reasons.
With the cover open, you can also access the LCD display, the
Master Up and Down buttons, the individual Zone Up
and Down buttons, the Zone identification and status buttons,
the Zone level indicators, and the programming/navigation
buttons.
Figure 15 - D4200 Buttons
1 9 2 10 3 11 4 12 5 13 6 14 15 16
M
as
t
e
r
