7 Description of Function Codes NICE5000 User Manual
- 132 -
frequency to the lowest within the allowable noise, which reduces the controller loss and
radio frequency interference.
If the carrier frequency is low, output current has high harmonics, and the power loss and
temperature rise of the motor increase.
If the carrier frequency is high, power loss and temperature rise of the motor declines.
However, the system has an increase in power loss, temperature rise and interference.
Adjusting the carrier frequency will exert inuences on the aspects listed in the following
table.
Table 7-1 Inuences of carrier frequency adjustment
Carrier frequency
Low High
Motor noise
Large Small
Output current waveform
Bad Good
Motor temperature rise
High Low
Controller temperature rise
Low High
Leakage current
Small Large
External radiation interference
Small Large
Note
On certain environment conditions (the heatsink temperature is too high), the system will reduce
the carrier frequency to provide overheat protection for the controller, preventing the controller
from being damaged due to overheat. If the temperature cannot reduce in this case, the controller
reports the overheat fault.
Group F1: Motor Parameters
Function Code Parameter Name Setting Range Default Unit Property
F1-00
Group F1 security password 0–65535
01000 - ●
You are allowed to view and modify group F1 parameters only after entering the security
password.
Function Code Parameter Name Setting Range Default Unit Property
F1-01
Rated motor power 1.1–132.0
Model
dependent
kW ★
F1-02
Rated motor voltage 50–600
380 V ★
F1-03
Rated motor current 0.00–655.00
25 A ★
F1-04
Rated motor frequency 0.00–99.00
50 Hz ★
F1-05
Rated motor speed 0–3000
1460 RPM ★
Set these parameters according to the motor nameplate.
Each time F1-01 is changed, F1-06 to F1-10 are restored to the default setting for the
