NICE5000 User Manual 2 Product Information
- 31 -
Controller Model
A
(mm)
B (mm)
H
(mm)
W (mm) D (mm)
Φ
(mm)
Weight
(kg)
NICE-LWX-4018-A/B/C0
300 339 361 410 172 7 19.1NICE-LWX-4022-A/B/C0
NICE-LWX-4030-A/B/C0
NICE-LWX-4037-A/B/C0
260 580 600 385 265 10 32NICE-LWX-4045-A/B/C0
NICE-LWX-4055-A/B/C0
NICE-LWX-4075-A/B/C0
343 678 700 473 307 10 47
NICE-LWX-4090-A/B/C0
NICE-LWX -4110-A/B/C0
449 903 930 579 380 10 90NICE-LWX -4132-A/B/C0
NICE-LWX -4160-A/B/C0
Note
For the models of other higher power classes (such as above 160 kW) that are still not often
applied onsite, the preceding table does not list the mounting dimensions. If you need such
models, directly contact Monarch.
2.6 Optional Parts
If any optional part in the following table is required, specify it in your order.
Table 2-4 Optional parts of the NICE5000
Name Model Function Remark
External
braking unit
MDBUN
It is provided for the NICE5000 of 37 kW
and above.
For details,
see section 3.7
"Selection of Braking
Components".
PG card
MCTC-PG-A2
It is used to adapt to the push-pull and
open-collector incremental encoders.
-
MCTC-PG-D
It is used to adapt to the UVW differential
encoder and applied to synchronous
motor.
It requires 5 V power supply.
-
MCTC-PG-E
It is used to adapt to the SIN/COS
encoder.
-
MCTC-PG-F1
It is used to adapt to the absolute encoder
(Heidenhain ECN413/1313)
