Innity
®
Enteral Feeding Pump Operator’s Manual
32
Innity AC Adapter/Charger
Order Number 23401-001
Plug AC Adapter/Charger into a wall outlet and
plug connector into pump to operate on AC
power and/or recharge battery (Figure 6-1).
Innity Pole Clamp
Order Number 11981-001
Thread bolt into receptacle on the back of
pump and tighten gray wheel to mount pump
on clamp. If gray wheel is slightly loosened,
pump can be rotated to snap into dierent
positions. Retighten gray wheel when pump
is in the desired position. Tighten black wheel
to mount clamp on a pole (Figure 6-2).
Innity
Adjustable Angle Pole Clamp
Order Number 29152-001
Thread bolt into receptacle on the back of
pump and tighten knob to mount pump on
clamp. If knob is slightly loosened, pump can
be rotated to snap into dierent positions.
Retighten knob when pump is in the desired
position. Tighten black wheel to mount clamp
on a pole. Pull pin to adjust angle (Figure 6-3).
6. ACCESSORIES
6. ACCESSORIES
Figure 6-1 AC Adapter/Charger
Figure 6-2 Pole Clamp / Pole Clamp
with Pump Attached to IV Pole
Figure 6-3 Adjustable Angle Pole
Clamp / Adjustable Angle Pole Clamp
with Pump Attached to IV Pole

Moog Infinity Specifications

General

Model	Infinity
Type	Infusion Pump
Occlusion Pressure Settings	Low, Medium, High
Alarms	Occlusion, Low battery
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Manufacturer	Moog
Infusion Modes	Continuous, Intermittent
Display	LCD
Compatibility	Standard infusion sets
