Moog Infinity User Manual

Innity
®
Enteral Feeding Pump Operator’s Manual
34
6. ACCESSORIES
Innity Waist Pack
Order Numbers PCK3001 (black and gray)
Pack holds Innity with a 500 ml bag. Pump is secured with an elastic strap. A Velcro
strap secures the neck of the 500 ml bag. The tubing is loaded into pump and any
excess length of tubing can be secured with a Velcro tab. The downstream tubing then
feeds through a port at bottom of pack (either side).
Dimensions: 7” H x 11” W x 3” D (17.8 cm H x 27.9 cm W x 7.6 cm D)
Innity Backpack
Order Numbers PCK4001 (black and gray)
Pack holds Innity with a 500 ml bag or a 1200 ml bag. Pump is secured with a
Velcro
®
strap. A Velcro strap secures the neck of the 500 ml or 1200 ml bag. The
tubing is loaded into pump and any excess length of tubing can be secured
with a Velcro tab. The downstream tubing then feeds through a port at bottom
of pack (either side). Also included in this pack is a pocket that may be used to
hold an ice pack. Dimensions: 17” H x 8” W x 4” D (43.2 cm H x 20.3 cm W x 10.2 cm D)
Figure 6-10 Waist Pack Figure 6-11 Waist Pack (Cutaway View of
Internal Compartment and Straps)
Feeding
Bag Strap
Tubing
Strap
Tubing Strap
Pump
Strap
Figure 6-12 Backpack Figure 6-13 Backpack (Cutaway
View of Internal Compartments)
Figure 6-14 Backpack (Cutaway
View of Internal Straps)
Ice Pack Pocket
1200ml & 500ml
Bag Compartment
Pump Compartment
Feeding
Bag Strap
Tubing Strap
Tubing Strap

Moog Infinity Specifications

General

Model	Infinity
Type	Infusion Pump
Occlusion Pressure Settings	Low, Medium, High
Alarms	Occlusion, Low battery
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Manufacturer	Moog
Infusion Modes	Continuous, Intermittent
Display	LCD
Compatibility	Standard infusion sets
