Guidance and manufacturer’s declaration – electromagnetic emissions
The Innity is intended for use in the electromagnetic environment specied below. The customer or the user of the Innity should
assure that it is used in such an environment.
Emissions Test Compliance Electromagnetic environment - guidance
RF Emissions
CISPR 11
Group 1
The Innity uses RF energy only for its internal function. Therefore, its
RF emissions are very low and are not likely to cause any interference in
nearby electronic equipment.
RF Emissions
CISPR 11
Class B
Harmonic emissions
IEC 61000-3-2
Class B
The Innity is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low-voltage
power supply network that supplies buildings used for domestic
purposes.
Voltage uctuations/Flicker
emissions
IEC 61000-3-3
Complies
Guidance and manufacturer’s declaration – electromagnetic immunity
The Innity pump is intended for use in the electromagnetic environment specied below. The customer or the user of the Innity
pump should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic
environment - guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
± 8 kV contact
± 15 kV air
± 8 kV contact
± 15 kV air
Floors should be wood, concrete
or ceramic tile. If oors are covered
with synthetic material, the relative
humidity should be at least 30%.
Electrostatic fast
transient/burst
IEC 61000-4-4
± 2 kV for power supply lines
± 1 kV for input/output lines
100 kHz PRR
± 2 kV for power supply lines
± 1 kV for input/output lines
100 kHz PRR
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
2kV
(0, 90, 180, & 270° phase)
2kV
(0, 90, 180, & 270° phase)
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines
IEC 61000-4-11
<0 % U
T
(>95 % dip in U
T
) for
0.5 cycle
40 % U
T
(60 % dip in U
T
) for
5 cycles
70 % U
T
(30 % dip in U
T
) for
25/30 cycles
<0 % U
T
(>95 % dip in U
T
) for
250/300 cycles
<0 % U
T
(>95 % dip in U
T
) for
0.5 cycle
40 % U
T
(60 % dip in U
T
) for
5 cycles
70 % U
T
(30 % dip in U
T
) for
25/30 cycles
<0 % U
T
(>95 % dip in U
T
) for
250/300 cycles
Mains power quality should be that
of a typical commercial or hospital
environment. The Innity pump
allows continued operation during
power mains interruptions via the
internal battery.
Power frequency (50/60
Hz) magnetic eld
IEC 61000-4-8
30 A/m Class 2 (30 A/m) Power frequency magnetic elds
should be at levels characteristic
of a typical location in the typical
commercial or hospital environment.
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
9. ADDITIONAL TECHNICAL INFORMATION

Moog Infinity Specifications

General

Model	Infinity
Type	Infusion Pump
Occlusion Pressure Settings	Low, Medium, High
Alarms	Occlusion, Low battery
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Manufacturer	Moog
Infusion Modes	Continuous, Intermittent
Display	LCD
Compatibility	Standard infusion sets
