MPT-90 PRODUCT MANUAL This document contains U.S. export controlled technical data as regulated by the U.S. Export Administration Regulations 15 CFR Parts 730-774, export, disclosure or transfer contrary to U.S. law is prohibited.
Base connector – on base of unit, in a fixed position related to its mounting flange,
egressing out opposite the front at 180°.
The following list of acronyms are used in this manual:
DC Direct Current
EIA Electronic Industry Association
GIG-E Gigabit Ethernet, aka 1000BASE-T
GUI Graphic User Interface
HD-SDI High Definition-Serial Digital Interface
in Inches
I/O Input / Output
lbs. Pounds
mm millimeters
MPT Moog Pan & Tilt
PCB Printed Circuit Board
P & T Pan & Tilt, also known as Positioner
TIA Telecommunications Industry Association
VAC Volts Alternating Current
VDC Volts Direct Current
VRMS Volts Root Mean Square
1.4 Conventions Used in this Manual
Boldface highlights key user interface components. WARNING, CAUTION,
and NOTE highlight statements that identify potential hazards that may occur
if this equipment is not used properly.
IMPROPER USE OF THIS PRODUCT CAN CAUSE SEVERE
BODILY INJURY OR DAMAGE THE EQUIPMENT.
IMPROPER USE OF THIS PRODUCT CAN DAMAGE THE
EQUIPMENT.
NOTE
Notes contain important information about the product or procedure.
