H12+ Digital Recorder
The compact flash card slot and the battery compartment are accessible via the battery door of the H12+ Recorder.
Opening and Closing the Battery Door
To open the battery door, hold the latch (1) down and then depress and slide the battery door (2) until it stops.
Lift and remove the battery door.
To close the battery door, place the battery door on the H12+ as shown above and slide the door in the opposite
direction of the arrow (2) until the door snaps into place. It is recommended that latch (1) be depressed when closing
the battery door to prevent damage to the door and the latch assembly.
