Section 4
4-1
4
H12+ Disassembly
WARNING: No user serviceable parts are inside. Any modification of this device will void any and all
Manufacturer's Warranties and/or responsibilities. If you are not able to correct the
H12+Holter Recorder Module’s questionable operating state using the Troubleshooting guide
in the Operator's Manual, do not attempt to service it yourself. Contact Mortara Service at 1-
888-MORTARA (1-888-667-8272) or via email at TechSupport@mortara.com.
Parts List
H12+ Digital Recorder Assembly
Item
Number
Part Number:
Description:
Qty:
1
8340-002-50
H12+ HOUSING BOTTOM ASSEMBLY
1
2
26025-031-50
H12+ FRONT END PC BOARD ASSEMBLY
1
3
8340-007-01
SPRING DOOR RELEASE H12+
1
4
8340-004-50
H12+ RELEASE LATCH ASSEMBLY
1
5
8340-009-01
FILLER COMPACT FLASH H12+
1
6
26025-030-50
DIGITAL PC BOARD ASSEMBLY
1**
7
8340-001-50
H12+ HOUSING TOP ASSEMBLY
1
8
8312-024-50
BEZEL ASSEMBLY H12+
1
9
4160-025-01
KEYPAD 3 BUTTON H12+
1
10
6021-002
SCREW M2X16MM SLTD CHEESE HD MACH
STL
3
11
5400-013
LCD WITH RIBBON CABLE
1
12
7401-003
DOUBLE SIDED FOAM TAPE, 1/2”
2
13
9042-027-01
LABEL BACK H12+
1
14
8340-003-50
H12+ BATTERY DOOR ASSEMBLY
1
15
6021-003
SCREW M2X16 PHILIPS PNHD PLTD STEEL
3
16
8340-007-01
SPRING DOOR RELEASE H12+
1
17
6020-033-02
SCREW PH PNHD M2X4 DIN 7985 ZP STL CTD
2
18
26025-031-50
H12+ FRONT END PCB ASSEMBLY
1
19
9293-017-50
X-12/H12+ Patient cable AHA (Domestic)*
1
20
9293-017-51
X-12/H12+ Patient cable EC (International)*
1
21
9293-026-50
Large X-12/H12+ Patient Cable AHA (Domestic)*
1
22
9293-026-51
Large X-12/H12+ Patient Cable EC (International)*
1
23
26025-030-51
Digital Board H12+ 24H PC Assembly
1**
24
26025-030-52
Digital Board H12+ 48H PC Assembly
1**
*Note: Only one patient cable is required to operate the H12+. The difference between the 9293-017-5X cable and
the 9293-026-5X cable is the length of the cable.
**Note: Depending on the unit any one of these boards can be used.
